1TP TE029B

“NEXT” series menu driven daily digital thermostat, 230V, white color


Power supply: 230Vac 50-60Hz

Multilanguage menu

4.3” backlit LCD display

Backlit buttons

Output: 1 potential free changeover contact:
5 (3) A / 250Va.c.

ON / OFF operation mode with adjustable differential
from 0.2 - 1.2 ° C or modulating with control period
from 7 - 20 min

Temperature levels: 2 + anti-freeze

Temperature adjustable by 0,1°C sets

Pausing for household cleaning

Input for telephone programmer or remote contact

Summer / Winter control

Pump activation program

Temperature setting lock

User password

Installer password

Backlighting: timed and fixed

Temperature offset: adjustable according to product

Wall mounting

Temperature setting range: 5 - 37.7°C

Dimensions: (L x W x H) 128.5 x 88.5 x 26 mm
