Daily time switch with tappets and charge reserve - 1 DIN
Daily time switch with tappets and charge reserve - 1 DIN
TECHNICAL SPECIFICATIONS
Power supply voltage 230V a.c. 50 - 60Hz
Contact rated data 16 (2) A / 250V a.c.
Max program number (ON-OFF) 96 (art. 0170 / 0171)
ON - OFF minimum connection time 15’ (item 0170 - 0171)
Displays mechanical tappets ring
Max commutable power 3500 VA (for individual contact)
Max cross-section of wires to terminals 4 mm²
Protection degree (IP) IP 20 - IP 30 (with terminal covers) IP 40 (on rear of switchboard)
Type of output terminals with captive screw
Insulation class II
Charge reserve approx 100 h max
Type of reserve NiCd rechargeable battery
Time tolerance + - 1 sec/day
Operating temperature limits -10°C / +50°C
Storing temperature -10°C / +50°C
Type of installation DIN rail / wall-mounted / on rear of switchboard
Housing thermoplastic - grey RAL 7035
Type of use civil / tertiary / industrial
Controls mechanical tappets ring selector switch: fixed ON / timer position
Clock setting accuracy mechanical with reference index
Programming mechanical key ring
Dimensions (L x W x H) mm 1DIN 17.5 x 60 x 128
